FXC7000 AC-DC Series Data Sheet
Output Specifications
PARAMETER
Output Voltage
DESCRIPTION/CONDITIONS
An additional 1.0 Volt is provided to the output terminals to provide for
MIN
45.6
NOM
48
MAX
50.4
UNITS
V
Adjustment Range
load lead losses.
Output Power
Output Current
Continuous duty rating.
Continuous duty rating.
7000
145
Watts
A
Efficiency
Full rated load (208Vac).
88
91
%
Regulation
Load, Maximum deviation with 0 to 100% load change:
With Remote Sense connected:
0.2
Ripple & Noise
With Remote Sense not connected:
Utilizing Droop Current Share:
Line, Under all specified operating conditions.
Measured at mating connector w/ 0.01μF + 10μF Tant.
20 MHz BW:
100 MHz BW:
0.75
2.0
0.2
1
2
%
% p-p
Overshoot / Undershoot
Minimum Loads
Transient Response
Turn-On Delay
Turn-on Rise Time
Output voltage overshoot/undershoot at turn-on.
Minimum loading required to maintain regulation.
Maximum recovery time, to within 1% of initial set Time:
point due to a 25% load change, 1A/μS. Deviation:
Time required for initial output voltage stabilization after power-up.
Time required for output voltage to rise from 10% to 90%.
0
0
800
3.2
3
100
%
A
μs
%
s
ms
Interface Signals and Internal Protection
PARAMETER (NOTE 1,2)
AC Power Fail Warning
Auxiliary Power
DESCRIPTION/CONDITIONS
Warning provided prior to Vout dropping 5% after loss of AC input.
Output voltage - diode isolated. Inclusive of line, load, and initial tolerances.
MIN
4
11.6
NOM
12.0
MAX
12.4
UNITS
ms
V
Current Monitor
Output current.
Monitor output current over a compliance range of 0~10V.
Normal output:
0.10
500
mA
mA/A
Total error current:
0.5
0.5
mA
Current Share
Input Range Select Status
Loss of Phase Warning
Output Inhibit
Output Interlock
Static sharing deviation as a percent of full-load rating Active:
for loads >10%. Passive:
Maximum signal resistance in high input voltage range selection.
Warning provided prior to protective reduction in current limit.
Voltage required to enable supply (0.5 mA sink). (NOTE 3)
Voltage required to enable supply (6 mA sink). (NOTE 3)
500
5
10
0.10
1.0
1.0
%
ms
V
V
Output Overload Protection
Output Overload Warning
Output Short Circuit Protection
Straight line current limit (above approx. 5V Vout).
Signal level on overload.
Occurs on overload when Vout is below approx. 5V. Iavg:
149
2.2
25
156
90
A
V
A
May operate in burst-mode.
Output Voltage Fault Signal
Output Voltage Margin
Overtemperature/
Deviation from adjusted Vout that is considered as a fault.
Output voltage swing available through Margin pin (analog).
Time between fault warning and shutdown.
±3
±4.8
100
±4
±5.0
±5
±5.2
%
%
ms
Fan Failure Warning
Latching shutdown.
Overvoltage Protection
Latch style overvoltage protection.
55.2
57.6
60.0
V
Power Supply Present Signal
Resistance to logic ground upon insertion of supply.
1000
Remote Sense
Maximum load lead loss compensation (round trip).
1.0
V
NOTES: 1) All logic outputs listed below feature a standard active pull-down output with 0.4V max at 40 mA sink capability, and a 100k pull-up to 5V.
2) In addition to those listed below, signals and front-panel LEDs are provided to indicate: overtemperature/fan fault, AC phase
imbalance, output good, interlock open, and supply inhibited. The FXP also provides 4 LED’s indicating output loading.
3) Both signals must be pulled to logic ground for the unit to operate. Enables are 100% redundant internally for applications where redundant inhibit is desirable.
Contact factory for additional design details.
AUG 18, 2006 revised to JAN 09, 2007
Page 2 of 4
www.power-one.com
